Other function
★64 bits（CPU）ARMCortex-A53*2+A73*2，@1.5G HZ，（GPU）Mali-G51 ；RAM 2GB DDR4 ；（ROM）16G (EMMC5.1)；Android 8.0 operate system ，add APP application and download APK ；Inside with storage space
Language
Chinese、 Russian、English French.German ,Italy、Spanish、Portugal、Nertherlands
| 1. size of products | |
| Screen Size(mm) |
MODEL :JRT-65 ;1428,5x803,5mm MODEL:JRT-75 ; 1650x928mm MODEL:JRT-86 ;1895,04x1065,96mm |
| Maximum power | ≤80W( without OPS） |
| gross weight: | 58KG |
| Standby Power | ≤0.5W |
| 2. system spec | |
| chip | 64 bits（CPU）ARMCortex-A53*2+A73*2，@1.5G HZ |
| precessor | （GPU）dual core Mali-G51 |
| CPU | 1.5GHZ |
| SYSTEM | Android 8.0 |
| RAM | 2G（DDR4） |
| storage space | （ROM）16G (EMMC5.1)，TF card can extend |
| Resolution | 3840*216060Hz |
| resolution | 1920*1080@60Hz or 3840*2160@60Hz |
| 3. display spec | |
| aspect ratio | 16：9） |
| type | LED panel |
| Resolution | 3840*2160 |
| Brightness | 350 cd/㎡ |
| Contrast | 1200:01:00 |
| resolution | 3840（H）×2160（V） |
| Color Depth | 10bit, 1.07B |
| Refresh rate | 60HZ |
|
View Angle |
178° (H) 178° (V) |
| glass | 4mm Anti glare Ag |
| Backlight life | 50000 hours |
| 4. | TV |
| iamge type | PAL/SECAM/NTSC（Option） |
| Sound type | BG /DK /I/L |
| Channel saving | 200 |
| Decode | 3D digital comb filter 、3D image motion image denoising '3D motion adaptive digital comb filter |
| speaker | 10W 8ohm*2 |
| Audio frequency | balance， auto Vol control surround, balance device |
| input port | RS232*1 |
| HDMI2.0* 1 | |
| TF | |
| USB*2 | |
| USB2.0*2 | |
| RJ45 *1 | |
| HDMI 2.0* 2 | |
| VGA input | |
| YPBPR | |
| AV | |
| OUTPUT PORT | RJ45 |
| TOUCH PORT | |
| AV | |
| COAL | |
| HEADSET | |
| front port | 2*USB3.0 （Windows &Android both system and detect this port） |
| PC characters | Processor ：Intel I3 I5 I7 H110 |
| RAM：4GB（DDR3）8G（DDR3） | |
| display card：intergrate display card | |
| SSD ：128GB/256 OPTIONAL | |
| wireless Lan card: 2.4G（IEEE 802.11B/G/N） WIFI | |
| NIC:Gigabit Nic | |
| SOUND CARD :Intergrated Sound Chip | |
| Win10 professional（trial version） | |
| PC Port | HDMI OUT*1 |
| VGA OUT *1 | |
| USB （USB 2.0*3,USB 3.0*3） | |
| DP OUT | |
| RJ45 | |
| AUDIO-OUT | |
| MIC-IN | |
| Touch Parameter | Touch Technology ：Infared Touch |
| Touch Points ：20points | |
| Writing Mode :finger or any opaque object | |
| Accuracy :<2mm | |
| Response Time：5ms | |
| Cusor Speed :180 dot/s | |
| Connection Port :USB 2.0, USB 3.0 | |
| Operating System:Windows/Linux/Mac/Android | |
| Working Temperature:0℃-40℃ | |
|
Accessories |
Magnetic Pens*1, HDMI Cable*1, Touch USB, Power Cable*1, Remoter*1, Wall mounting bracket VESA: 400x300 for 65", 600x500 for 75", 800x400 for 86" |
